TEMCo HC0034 Low Profile Height Hydraulic Cylinder Puck 50 Ton, 0.63" Stroke (Optional Tonnages Availiable)

Capacity (Tons): 50 Stroke (in.): 0.63" Maximum Pressure (PSI): 10,000 Type: Telescoping Hydraulic Cylinder Action: Single acting - Pressure extend, Spring return Ram Material: Hard black oxide plated high carbon steel Shell Material: Proprietary Heat-treated Steel Oil Volume (Cubic in.): 6.163 in³ Effective Area (Square in.): 10.974 in² Closed Height (in.): 2.834" Extended Height (in.): 3.464" Weight (lbs): 17.7 Max Pressure: 10,000 PSI Minimum Operating Temperature: -15°C Connector Type: 3/8" NPT ISO 14540 quick hydraulic coupler with dust cap Coupler Specifications Standard: ISO 14540 Thread (between male poppet end and coupling ring): M30 x 1.5 mm Thread: 3/8" NPT Occlusion Type: Poppet Rated Pressure: 10,000 psi Rated Flow: 6 GPM Sealing Material: Nitrile Rubber (Buna-N, NBR)

• 50 US Ton Capacity. 0.63" Stroke
• Max Pressure 10,000 PSI. Single acting - Pressure extend, Spring return.
• Hard black oxide plated high carbon steel ram. Proprietary heat-treated steel shell.
• Connector Type: 3/8" NPT ISO 14540 quick hydraulic coupler with dust cap
• 5 Year Warranty from an American name. NON-GENERIC
